4G LTE Omni-Außenantenne 5dBi Wandhalterung SMA Male Steckverbindung
auf Lager
?
35.27 €
35.27 €
Detallierte Beschreibung
Die AOA-4G-5W-SMM ist eine omnidirektionale 4G/LTE-Antenne von ALFA Network für den Außeneinsatz mit IP67-Gehäuseschutz. Funktioniert in den Frequenzbändern 698-960 MHz SISO 1x1 mit 5 dBi Gewinn und 1710-2700 MHz SISO 1x1 mit 5 dBi Gewinn. Ausgestattet mit einem SMA Male Stecker.
Spezifikationen
Mobiles Netzwerk
Mobile Network Generation
4G (LTE)
Antenne
Antennen Design
Omni
Mobile Antenna Frequenzbereich und Verstärkung
0.698 - 0.96 (GHz) 4 (dBi), 1.71 - 2.7 (GHz) 5 (dBi)
Strahlbreite
360 °
Polarisation
Vertical
Kabellänge
3 m
VSWR
< 2
Impedanz
50 Ω
Maximale Eingangsleistung
100 W
Anschlüsse
RF Steckverbinder
(1) SMA Male
Physical Parameters
Farbe
Schwarz
Material
UV Plastik
Ingress Protection Code
IP67
Maße
Ø48 x 83 mm
Gewicht
0.22 kg
Betriebstemperatur
-40 °C bis 80 °C
Umwelt
Außen
Montagemethode
Wandhalterung
Eingeschätzte Windgeschwindigkeit
60 m/s
