4G LTE Omni-Außenantenne Magnetfuß 5dBi SMA Male Steckverbindung
auf Lager
?
35.62 €
35.62 €
Der Bestand ist nicht ausreichend. Bitte registrieren Sie sich, um einen Auftrag zu erteilen.
Detallierte Beschreibung
Die AOA-4G-5MGN-SMM ist eine omnidirektionale 4G/LTE Außenantenne von ALFA Network auf einem Magnetfuß. Funktioniert in den Frequenzbändern 698-960 MHz SISO 1x1 und 1710-2700 MHz SISO 1x1 mit 5 dBi Gewinn. Ausgestattet mit einem wasserdichten SMA Male Steckverbindung. Die Kabellänge beträgt 3 m.
Kompatible Produkte
Spezifikationen
Mobiles Netzwerk
Mobile Network Generation
Antenne
Antennen Design
Omni
Mobile Antenna Frequenzbereich und Verstärkung
0.698 - 0.96 (GHz) 2 (dBi), 1.71 - 2.17 (GHz) 5 (dBi), 2.4 - 2.7 (GHz) 4 (dBi)
Mobilantenne-Gewinn
2 dBi, 5 dBi, 4 dBi
Strahlbreite
360 °
Polarisation
Vertical
Kabellänge
3 m
VSWR
< 4
Impedanz
50 Ω
Maximale Eingangsleistung
50 W
Anschlüsse
RF Steckverbinder
(1) SMA Male
Physical Parameters
Farbe
Schwarz
Material
ABS Plastik
Ingress Protection Code
IP67
Maße
Ø110 × 120 mm
Gewicht
0.9 kg
Betriebstemperatur
-40 °C bis 70 °C
Umwelt
Außen
Montagemethode
Magnetisch
