QuPanel 5G/LTE Global MIMO 2x2, 5m
neuheit
neuheit
auf Lager
?
169.00 €
169.00 €
Detallierte Beschreibung
Technische Daten
Kompatible Produkte
Spezifikationen
Mobiles Netzwerk
Mobile Network Generation
4G (LTE), 5G (NR)
Antenne
Antennen Design
Panel
Mobile Antenna Frequenzbereich und Verstärkung
0.617 - 0.96 (GHz) 6 (dBi), 1.7 - 2.7 (GHz) 7 (dBi), 3.3 - 4.6 (GHz) 7 (dBi), 4.7 - 6.0 (GHz) 5.5 (dBi)
Mobilantenne-Gewinn
6 dBi, 7 dBi, 7 dBi, 5.5 dBi
Strahlbreite
80 °
VSWR
< 3
Impedanz
50 Ω
Anschlüsse
RF Steckverbinder
(2) SMA Male
Physical Parameters
Material
Aluminum, ABS Plastik, Glasfaser, Polytetrafluorethylen
Ingress Protection Code
IP67
Maße
486 x 292 x 106 mm
Gewicht
2.8 kg
Betriebstemperatur
-40 °C bis 80 °C
Umwelt
Außen
Montagemethode
Wandhalterung, Mastenhalterungen
